FAG 30204-A Bearing

FAG 30204-A tapered roller bearings

Also known as : 30204-A,

• Inside Diameter: 20 mm
• Outside Diameter: 47 mm
• Width: 15.25 mm
• Basic dynamic load rating: 27 kN
• Basic static load rating: 27 kN

Inquire Now

FAG 30204-A Bearing

model	30204-A
d	20 mm
D	47 mm
T	15.25 mm
a	12 mm
B	14 mm
C	12 mm
Ca min	2 mm
Cb min	3 mm
Da max	41 mm
Da min	40 mm
Db min	43 mm
d1	34.5 mm
da max	27 mm
db min	26 mm
r1,2 min	1 mm
r3,4 min	1 mm
ra max	1 mm
rb max	1 mm
Cr	27000 N, Basic dynamic load rating, radial
C0r	27000 N, Basic static load rating, radial
Limiting speed	16800 1/min
Reference speed	10200 1/min
Cur	2900 N, Fatigue limit load, radial
e	0.35
Y	1.74
Y0	0.96
mass	0.132 kg

Nodes bearings have FAG 30204-A roller bearings in stock, more related FAG bearings: FAG tapered roller bearings catalogue, main dimensions to DIN ISO 355 / DIN 720, separable, adjusted or in pairs.
