INA NKI6/16-TV-XL needle bearings
Also known as : NKI6/16-TV-XL
- Inside Diameter: 6 mm
- Outside Diameter: 16 mm
- Width: 16 mm
- Basic dynamic load rating: 6.6 kN
- Basic static load rating: 7.1 kN
INA NKI6/16-TV-XL Bearing
INA NKI6/16-TV-XL Bearing details
| d | 6 mm | |
|---|---|---|
| D | 16 mm | |
| B | 16 mm | |
| F | 9 mm | |
| rmin | 0,3 mm | |
| s | 2 mm | Axial displacement |
| m | 17,4 g | Mass |
| Cr | 6600 N | Basic dynamic load rating, radial |
| C0r | 7100 N | Basic static load rating, radial |
| Cur | 1190 N | Fatigue limit load, radial |
| nG | 31000 1/min | Limiting speed |
| nB | 28000 1/min | Reference speed |
| With closing rings, without lubrication hole and without lubrication groove. |
As INA bearing distributor, Nodes bearings have INA NKI6/16-TV-XL needle bearings in stock, light series.
INA NKI6/16-TV-XL bearing cross reference
INA HK0606 bearing
6mm x 10mm x 6mm
INA HK0608 bearing
6mm x 10mm x 8mm
INA HK0609 bearing
6mm x 10mm x 9mm
IKO TAFI61616 bearing
6mm * 16mm * 16mm
INA IR6X9X12-XL bearing
6mm x 9mm x 12mm
INA IR6X9X16-XL bearing
6mm x 9mm x 16mm
INA IR6X10X10-IS1-XL bearing
6mm x 10mm x 10mm
INA NAO6X17X10-TV-IS1-XL bearing
6mm x 17mm x 10mm
INA NK6/10-TV-XL bearing
6mm x 12mm x 10mm
INA NK6/12-TV-XL bearing
6mm x 12mm x 12mm
INA NKI6/12-TV-XL bearing
6mm x 16mm x 12mm
