NSK 51115 Bearing

NSK 51115 Thrust Ball Bearings

Also known as : 51115

  • Inside Diameter: 75 mm
  • Outside Diameter: 100 mm
  • Width: 19 mm
  • Basic dynamic load rating: 43.5 kN
  • Basic static load rating: 131 kN

Inquire Now


NSK 51115 Bearing

NSK 51115 Bearing details

model 51115
d 75 mm
D 100 mm
T 19 mm
d1 100 mm
D1 77 mm
rmin. 1.0 mm
Ca 43500 N
C0a 131000 N
Limiting speeds 2200 min-1 (Grease)
Limiting speeds 3400 min-1 (Oil)
da 90 mm
Da 85 mm
ra 1.0 mm
Mass 0.389 kg (approx.)

As a NSK Bearing distributor, Nodes bearings have NSK 51115 thrust ball bearings in stock. more related bearings: Thrust ball bearings.

NSK 51115 bearing cross reference

NSK 51215 bearing
75mm x 110mm x 27mm
NSK 51315 bearing
75mm x 135mm x 44mm
NSK 51415 bearing
75mm x 160mm x 65mm
NSK 53215 bearing
75mm x 110mm x 28.3mm
NSK 53315 bearing
75mm x 135mm x 48.1mm
NSK 53415 bearing
75mm x 160mm x 69mm
NSK 53215U bearing
75mm x 110mm x 32mm
NSK 53315U bearing
75mm x 135mm x 52mm
NSK 53415U bearing
75mm x 160mm x 75mm
FAG 51115 bearing
75mm x 100mm x 19mm
