NTN 5211S double row angular contact ball bearings
Also known as : 3211
- Inside Diameter: 55 mm
- Outside Diameter: 100 mm
- Width: 33.3 mm
- Basic dynamic load rating: 56 kN
- Basic static load rating: 49 kN
NTN 5211S Bearing
NTN 5211S Bearing details
| Part Number | 5211S |
|---|---|
| Brand | NTN |
| Catagory | Double Row Angular Contact Ball Bearings |
| d | 55 mm |
| D | 100 mm |
| B | 33.3 mm |
| rs min | 1.5 mm |
| Cr | 53 kN, Basic load ratings, dynamic |
| C0r | 43.5 kN, Basic load ratings, static |
| Limiting speeds |
4300 min-1, grease 5600 min-1, oil |
| Load center | 50.1 mm |
| Mass | 0.96 kg |
NTN 5211S double row angular contact ball bearings is designed by arranging two single row angular contact bearings back-to-back in duplex to form one united bearing with a contact angle of 25°.
NTN 5211S bearing cross reference
SKF 3211 A bearing
55mm x 100mm x 33.3mm
FAG 3211-BD-XL bearing
55mm x 100mm x 33.3mm
FAG 3211-BD-XL-TVH bearing
55mm x 100mm x 33.3mm
NTN 7911 bearing
55mm x 80mm x 13mm
NTN 7011 bearing
55mm x 90mm x 18mm
NTN 7211 bearing
55mm x 100mm x 21mm
NTN 7211B bearing
55mm x 100mm x 21mm
NTN 7311 bearing
55mm x 120mm x 29mm
