SKF 6202-2RSH single row deep groove ball bearings
Also known as : 6202-2RSH, 6202DDU
- Inside Diameter: 15 mm
- Outside Diameter: 35 mm
- Width: 11 mm
- Basic dynamic load rating: 8 kN
- Basic static load rating: 3.7 kN
SKF 6202-2RSH Bearing
SKF 6202-2RSH Bearing details
model | 6202-2RSH |
---|---|
d | 15 mm |
D | 35 mm |
B | 11 mm |
d2 | 18.6 mm |
D2 | 30.35 mm |
r1,2 min. | 0.6 mm |
da min | 19.2 mm |
da max | 19.4 mm |
Da max | 30.8 mm |
ra max | 0.6 mm |
C | 8 kN, Basic dynamic load rating |
C0 | 3.7 kN, Basic static load rating |
Pu | 0.16 kN, Fatigue load limit |
Limiting speed | 13000 r/min |
kr | 0.025, Calculation factor |
f0 | 13, Calculation factor |
Mass | 0.0463 kg |
SKF 6202-2RSH ball bearings, SKF Explorer, deep groove ball bearing, Single-Row, Contact seal, NBR, on both sides. more related SKF products see SKF deep groove ball bearings catalogue.
