SKF 7216 BECBP Bearing

7216BECBP SKF angular contact ball bearing

Also known as : 7216-B-XL-TVP-UA

  • Inside Diameter: 80 mm
  • Outside Diameter: 140 mm
  • Width: 26 mm
  • Basic dynamic load rating: 85 kN
  • Basic static load rating: 75 kN

Inquire Now


SKF 7216 BECBP Bearing

SKF 7216 BECBP Bearing details

7216 BECBP SKF
Part Number 7216 BECBP
Brand SKF
Description Single row angular contact ball bearing
SKF Explorer
Dimensions
d 80 mm Bore diameter
D 140 mm Outside diameter
B 26 mm Width
d1 103.55 mm Shoulder diameter of inner ring (large side face)
d2 91.44 mm Shoulder diameter of inner ring (small side face)
D1 117.85 mm Shoulder diameter of outer ring (large side face)
a 59 mm Distance side face to pressure point
r1,2 min. 2 mm Chamfer dimension
r3,4 min. 1 mm Chamfer dimension
Abutment dimensions
da min. 91 mm Diameter of shaft abutment
Da max. 130 mm Abutment diameter housing
Db max. 134 mm Diameter of housing abutment
ra max. 2 mm Radius of fillet
rb max. 1 mm Radius of fillet
Calculation data
C 85 kN Basic dynamic load rating
C0 75 kN Basic static load rating
Pu 3.05 kN Fatigue load limit
  5600 r/min Reference speed
  5600 r/min Limiting speed
A 0.0801 Minimum axial load factor
kr 0.095 Minimum radial load factor
e 1.14 Limiting value
Mass
Mass 1.45 kg
