IKO GE40ES-2RS spherical plain bearings | 40x62x28mm
Also known as : GE40ES-2RS
- Inside Diameter: 40 mm
- Outside Diameter: 62 mm
- Width: 28 mm
- Basic dynamic load rating: 114 kN
- Basic static load rating: 686 kN
IKO GE40ES-2RS
IKO GE40ES-2RS Bearing details
| Identification number | GE40ES-2RS |
|---|---|
| Type | Spherical plain bearings |
| Mass | 0.315 kg |
| d | 40 mm |
| D | 62 mm |
| B | 28 |
| C | 22 mm |
| dk | 53 mm |
| r1s min | 0.6 mm |
| r2s min | 1 mm |
| Permissible tilting angle degree a1 | 4 |
| Dynamic load capacity | 114 kN |
| Static load capacity | 686 kN |
Nodes bearings have IKO GE40ES-2RS spherical bushings, Steel-on-steel Spherical Bushings, in stock.
