FAG 3217-B-2Z-TVH bearings | Dimensions: 85x150x49.2mm
Also known as : 3217-B-2Z-TVH
- Inside Diameter: 85 mm
- Outside Diameter: 150 mm
- Width: 49.2 mm
- Basic dynamic load rating: 135 kN
- Basic static load rating: 127 kN
FAG 3217-B-2Z-TVH Bearing
FAG 3217-B-2Z-TVH Bearing details
| Number | 3217-B-2Z-TVH | |
|---|---|---|
| Type |
Angular contact ball bearings main dimensions to DIN 628-3, double row, gap seals on both sides, contact angle α = 25° |
|
| d | 85mm | |
| D | 150mm | |
| B | 49,2mm | |
| a | 75,9mm | |
| D2 | 135,1mm | |
| Da max | 139mm | |
| d2 | 102,3mm | |
| da min | 96mm | |
| ra max | 2mm | |
| rmin | 2mm | |
| α | 25° | Contact angle |
| m | 3,3kg | Mass |
| Cr | 135000N | Basic dynamic load rating, radial |
| C0r | 127000N | Basic static load rating, radial |
| Cur | 5900N | Fatigue limit load, radial |
| nG | 33501/min | Limiting speed |
| nϑr | 49001/min | Reference speed |
Nodes bearings have FAG 3217-B-2Z-TVH bearings in stock, FAG bearings, main dimensions to DIN 628-3, double row, gap seals on both sides, contact angle α = 25°.
